5.3.2 USB Connector 2/3 (USB2/3)
USB Ports 2 and 3 are mounted together with DP1 port.
Note Type Signal PIN Signal Type Note
1 PWR 5V/SB5V 1 2 3 4 GND PWR
IO USB3- USB3+ IO
1 PWR 5V/SB5V 1 2 3 4 GND PWR
IO USB2- USB2+ IO
Note 1: In order to meet the requirements of USB standard, the 5V input supply must be at least 5.00V.
5.3.3 USB Connector 4/5 (USB4/5)
USB Ports 4 and 5 are mounted together with ETH1 port.
Note Type Signal PIN Signal Type Note
1 PWR 5V/SB5V 1 2 3 4 GND PWR
IO USB5- USB5+ IO
1 PWR 5V/SB5V 1 2 3 4 GND PWR
IO USB4- USB4+ IO
Note 1: In order to meet the requirements of USB standard, the 5V input supply must be at least 5.00V.
Signal Description
USB2+ USB2-
USB3+ USB3-
Differential pair works as Data/Address/Command Bus.
5V/SB5V
5V supply for external devices. SB5V is supplied during powerdown to allow
wakeup on USB device activity. Protected by resettable 1A fuse covering both USB
ports.
Signal Description
USB4+ USB4-
USB5+ USB5-
Differential pair works as Data/Address/Command Bus.
5V/SB5V
5V supply for external devices. SB5V is supplied during powerdown to allow wakeup
on USB device activity. Protected by resettable 1A fuse covering both USB ports.
