Healthy LED (LED2)
The AdvancedTCA LED2 is green or amber and indicates a Healthy condition. The healthy LED indicates if the
blade is powered up and all voltages and temperatures are within specifications. During normal operation,
this LED is ON (green). This LED is also ON (amber) when one of the RTM8242 voltage or temperature sensor
pass a threshold.
2.6.4
SFP+ and SFP LED
The Green LEDs indicate the link status of the connection. The LED is ON when there is a link, otherwise it’s
OFF.
