AT8902

Hardware Description

Page 3 - 22

AT8902 User Guide

Switch LED Assignment

Table 3-19: Switch LED Assignment

Switch LED

Number

Base Interface Fabric Interface

Logical ATCA

Slot

1

SMCA/B (Ch 1)

-

ShMC (s)

2

Ch 2

Ch 1

(other Hub)

3

Ch 3

Ch 2

3

4

Ch 4

Ch 3

4

5

Ch 5

Ch 4

5

6

Ch 6

Ch 5

6

7

Ch 7

Ch 6

7

8

Ch 8

Ch 7

8

9

Ch 9

Ch 8

9

10

Ch 10

Ch 9

10

11

Ch 11

Ch 10

11

12

Ch 12

Ch 11

12

13

Ch 13

Ch 12

13

14

Ch 14

Ch 13

14

15

Ch 15

Ch 14

15

16

Ch 16

Ch 15

16
