AT8902 Hardware Description
Page 3 - 10 AT8902 User Guide
17 Extended RTM, AMC_B1_P17
18 Extended RTM, AMC_B1_P18
19 Extended RTM, AMC_B1_P19
20 Extended RTM, AMC_B1_P20
CLK1 - To backplane CLK1A or CLK1B
CLK2 - To backplane CLK2A or CLK2B
CLK3 - From backplane CLK3A or CLK3B
Table 3-11: AMC B2 Channel Assignment
Channel Region Connection
0 GbE Local Base Switch 0/23
1 GbE -
2 SATA/FC AMC B1, channel 2
3 SATA/FC RTM, STOR1
4 Fabric 10GbE Uplink 0/25[0]
5 Fabric 10GbE Uplink 0/25[1]
6 Fabric 10GbE Uplink 0/25[2]
7 Fabric 10GbE Uplink 0/25[3]
8 Fabric 10GbE Uplink 0/26[0]
9 Fabric 10GbE Uplink 0/26[1]
10 Fabric 10GbE Uplink 0/26[2]
11 Fabric 10GbE Uplink 0/26[3]
12 - -
13 Extended -
14 Extended -
15 Extended -
16 Extended -
17 Extended RTM, AMC_B2_P17
18 Extended RTM, AMC_B2_P18
19 Extended RTM, AMC_B2_P19
20 Extended RTM, AMC_B2_P20
CLK1 - To backplane CLK1A or CLK1B
CLK2 - To backplane CLK2A or CLK2B
CLK3 - From backplane CLK3A or CLK3B
Table 3-10: AMC B1 Channel Assignment (Continued)
Channel Region Connection
