Introduction CP-RIO3-04S
Page 1 - 6 ID 1036-1669, Rev. 1.0
1.3 Technical Specification
Table 1-1: CP-RIO3-04S Main Specifications
CP-RIO3-04S SPECIFICATIONS
Fr
ont
Panel
Interfaces
VGA One VGA interface on a 15-pin, D-Sub connector, J7, for connecting a
standard analog monitor
Ethernet Two Gigabit Ethernet interfaces implemented as a dual RJ-45 connector,
J10A/B
COM1 One serial RS-232 port (COM1) on an RJ-45 connector, J2
Onboard
Interface
s
SATA Two SATA II interfaces (with SATA II repeater) implemented as two
onboard connectors, J5 and J6, for connecting external SATA devices via
a SATA cable
COM2 One onboard serial port (COM2) implemented as a 10-pin, 2.54 mm con-
nector, J3
Peripheral Control One 10-pin peripheral control connector, J13, with the following features:
• Fan speed monitor input
• Fan speed control output
• Power supply sleep mode output
• Wake-up / sleep input
CompactPCI One CompactPCI connector, rJ2 for connecting the CP-RIO3-04S to the
backplane
General
Temperature Range Operational: 0°C to +60°C Standard
Storage: -55°C to +85°C Without any additional components
Mechanical 3U, 4HP, CompactPCI-compliant form factor
Dimensions 100 mm x 80 mm
Board Weight 120 g
Note ...
When additional components are installed, refer
to their operational specifications as this will influ-
ence the modules’ operational and storage tem-
perature.
