CP381 Configuration
ID 24107, Rev. 01 © 2002 PEP Modular Computers GmbH Page 4 - 11
4.3.7 Hardware Debug/Test Registers
These registers are for internal test and debug only. The Common Status Register contains
Logic-Version and PCB -Version. The Common Control Register is a read/write register with-
out any further functionality. Neither of these registers should be used by standard software.
Table 4-12: Hardware Debug Register Bit Map
Bits Type Default Function
31-0 r/w 0 Used for test purposes
Table 4-13: Hardware Status Register Bit Map
Bits Type Default* Function
31-16 r 0 Reserved
15-8 r 00 HW Version (PCB Index)
7-0 r 01 Logic Version
Note...
The HW version starts with 0, the Logic version starts with 1. At each further
release it will be incremented by 1.
