Introduction CP381
Page 1 - 10 © 2002 PEP Modular Computers GmbH ID 24107, Rev. 01
1.7 Applied Standards
The PEP Modular Computers’ CompactPCI systems comply with the requirements of the fol-
lowing standards:
1.8 Related Publications
Table 1-4: CP381 Analog Input Specifications
TYPE DESCRIPTION
Input Voltage Range Low: -3V to +5V
High: +11V to +30V
Channels 30 channels
Channel Connections 2 pins per channel
Input Filter (edge frequency) 10 kHz
Input Protection 8 kV ESD
Isolation 2 kV process to system
Input Impedance Minimum: 1.5 k ohm
Maximum: 6 k ohm at 30V
Table 1-5: Applied Standards
TYPE STANDARD
CE
Emission EN50081-1
Immunity, Industrial Environment EN50082-2
Immunity, IT Equipment EN55024
Electrical Safety EN60950
MECHANICAL Mechanical Dimensions IEEE 1101.1
ENVIRONMENTAL TESTS
Vibration, Sinusoidal IEC68-2-6
Random Vibration, Broadband IEC68-2-64 (3U boards)
Permanent Shock IEC68-2-29
Single Shock IEC68-2-27
Table 1-6: Related Publications
ISSUED BY DOCUMENT
CompactPCI
Systems
PICMG CompactPCI Specification, V. 2.0, Rev. 3.0
PEP Modular Computers CompactPCI Systems Manual (ID 19953)
