The uEFI Shell
CP3002/-RC/-RA uEFI BIOS
Page 38
ID 1042-8946, Rev. 3.0
P R E L I M I N A R Y
SETTINGS:
pxe:
Select PXE boot network adapter
disabled:
No PXE boot available
[all]:
Try all Ethernet devices round robin for PXE boot
eth_a:
Try only Ethernet port A for PXE boot
eth_b:
Try only Ethernet port B for PXE boot
eth_c:
Try only Ethernet port C for PXE boot (CP3002-RC/-RA only)
eth_d:
Try only Ethernet port D for PXE boot (CP3002-RC/-RA only)
Note: On the CP3002, both eth_a and eth_b ports are available
either on the front or the rear I/O.
On the CP3002-RC/-RA, all Ethernet ports are available only on
the rear I/O.
StorageOrom:
Launch Storage PCI Option ROMs
disabled:
Do not launch storage PCI option ROMs. This includes the
onboard RAID option ROM.
[enabled]:
Launch storage option ROMs, if present
HyperThreading:
Enable/Disable Hyper-Threading Technology
CpuTurbo:
Enable/Disable CPU Turbo Boost Technology
CpuC:
Enable/Disable C states when the CPU is not 100% utilized
PrimaryDisplay:
Select primary display device
[auto]:
Automatically detect primary display device
igd:
Use internal graphics, if enabled
peg:
Try to use video on the PCIe graphics port, if present
pci:
Try to use video on the PCI bus first
SataMode:
Determines how SATA controllers operate
[ide]:
SATA ports operate as two IDE controllers
ahci:
SATA ports operate as one 6-port AHCI controller
raid:
SATA ports operate as one 6-port RAID controller
com_a:
COM A port configuration
[rear]: com_a
port signal is routed to the rear I/O
extension: com_a
port signal is routed to the 8HP extension
module
Note: This option has no effect if no rear I/O is attached to the CP3002.
On the CP3002-RA/-RC this option is not present as the com_a
port signal is fixed to rear I/O.
kboardconfig (continued)
