Gastroback 40123 Design Juicer - Manual (Page 9)

39
Operating your Design Juicer
Step 5:
Juice will flow into the jug and the separated
pulp will accumulate in the integrated pulp
container.
ATTenTIOn: Do not allow the pulp container
to overfill as this may affect the operation of the
appliance (refer to disassembling instructions).
reassemble machine to continue juicing.
To minimise cleaning, line the
pulp container with a plastic
freezer bag to collect the pulp.
empty the pulp container during juicing
The pulp container can be emptied during juicing
by turning the appliance ‘Off’ at the control panel
and then carefully removing the pulp container.
remove the pulp container by tilting the pulp
container slightly to the right and unlatch it
from under the juicer cover and the container
support extending from under the motor base.
replace the empty pulp container into position
before continuing to juice.
nOTe: Do not use force removing the pulp
container to avoid damage to the juicer cover.
nOTe: in case that the appliance slows down,
stumbles or stops all of a sudden turn off the
appliance immediately and pull the plug to
avoid overheating. Operate according to the
instructions ´Trouble shooting guide`.
WARnInG: Never use fingers to push food
down the feed chute or to clear the feed chute.
Always use the food pusher provided.
nOTe: Pay attention not to overflow the jucie jug.
As soon as you finished operating turn the
appliance ´OFF`. Always turn the appliance
´OFF` and pull the plug when the appliance is
not in use and you finished the operation.
clean the appliance in accordance to the
instructions in chapter ‘care and cleaning`. Do
not leave any food dry on the surfaces of the
appliance or the filter basket.
Step1:
Wash your selection of fruit and vegetables
before juicing.
nOTe: Most fruit and vegetables such
as small apples, carrots and cucumber
will not need to be cut to size as these
will fit into the feed chute whole. When
juicing carrots place the tip of the carrot
into the feed chute last.
Step 2:
ensure the juicer is correctly assembled. ensure
the stainless steel filter is thoroughly cleaned
before each use (refer to ´care and cleaning`).
ensure you place the juice jug under the spout
before commencing juicing.
Step 2 a: Working with the juice jug
The juice jug consist of the jug
with scale, a froth seperator and
the lid. insert the froth separator
from the top into the jug and
close the jug with the lid. Place
the juice jug infront of the spout
and ensure that the juice can
run right into the jug. This way
you can avoid splatter.
ATTenTIOn: ensure not to overfill the juice jug
when operating the juicer. Over floating liquid
could run under the motor block and cause
damage to the appliance.
Step 3:
Plug the power cord into a 220/230V power
outlet and turn the power ‘ON’. Push the ‘ON/
OFF’ button to ‘ON’.
Step 4:
With the motor running, place food into the
feed chute. using the food pusher, gently
guide food down the feed chute.
To extract the maximum amount of
juice, always push the
food pusher down slowly.
