Standard Configuration MODEL 2075 MINIMAST™
2 © EMC TEST SYSTEMS, L.P. – MARCH 2002
REV D – PN 399235
A safety brake is mounted on the carrier assembly. In the event
that the carrier is released from its rope suspension, a spring-
loaded lever jams the brake into position against the mast and
locks the carrier so that further vertical movement is restricted.
Mylar rope guy lines are provided for outdoor installations and
must be firmly anchored to provide vertical stability.
STANDARD CONFIGURATION
• Dual-Voltage Motor: 100/115 VAC or 220/240 VAC switch-
selectable
• Input frequency 50 Hz or 60 Hz
• Castered platform for portability
• Sectional mast
• Air polarization antenna mount
• Ten meter fiber-optic control cable for inside chamber
• Three meter fiber-optic control cable for connection to Model
2090 outside chamber
• Two ST to ST bulkhead feedthroughs
• Maximum loading 10.0 kg (22.0 lb)
• Overall height 4.61 m (15.1 ft) with all sections of mast
installed, sections can be removed for lower heights
• Base dimensions 0.90 m by 0.90 m (2.95 ft by 2.95 ft)
• Weight 81.2kg (179.0 lb)
Archived 3/18/10
