Series H-491198-36 Battery Charger | 39
Appendix D: HI-4433 Operating Protocols
The following information assumes that the optional HI-4413P Fiber Optic/RS232
Interface was purchased and is capable of communicating directly with an HI-
4433 probe via computer. No system readout is required when using this
configuration.
C OMMUNICATION P ROTOCOL
Data Type: RS-232 Serial
Data Mode: Asynchronous
Word Length: 7 bit
Parity: Odd
Stop Bits: 1
Data Rate: 9,600 baud
I NFORMATION T RANSFER P ROTOCOL
The HI-4433 series probes only respond to commands from another device; they
transmit no data without first receiving instructions to do so.
C OMMAND S TRUCTURE
Probe
Command
Description Probe Response
Axxx Axis enable/disable.
• x=E (enable) or D
(disable)
• xxx order=X axis, Y
axis, Z axis
B
Read battery voltage. Bxx.xx,
• xx.xx=battery voltage
