Specifications | 15
Specifications
General Specifications
Calibration Accuracy
• Overall +2/-3 dB*
• At calibration points ±0.5 dB*
*Absolute accuracy to NIST ± 1.0 dB
Isotropicity ± 0.5 dB
Linearity ±0.5 dB
Environmental
• Operating Temp. 10ºC to 40ºC
(50º F to 104ºF)
• Humidity 5% to 95%*
*relative humidity, non-condensing
Fiber Optic Cable
Connector
Standard FSMA
Battery
3.6 VDC, 14000mA-h rechargeable Nickel-
Cadmium (NiCd), 20 hours of continuous
operation
Battery Charger 115/230 VAC, approximately 1 hour
Size
• Length* 559mm (22.0 in.)
• Probe Diameter 102mm (4.0 in.)
• Weight* 0.57 kg (20 oz)
*Including electronics housing
Probe Mount
¼ - 20 UNC tapped hole (internal thread) in base
of probe
