Ets lindgren, Carrier,b/s,2171b, None – ETS-Lindgren 2171B Boresight Antenna Tower User Manual
Page 60: Revisions
A
A
10
2
23
33
15
8
30
47 48 50 49
62
24
29
29
66
77
76
25
31
36
26
20
77
65
76
64
5
1
76
63
11
17
22
39
74
75
73
36
71
72
13
2
43
76
45
76 53
76
76 4
68
61
52 21
55
60
59
119614 & 119613
34
39
8
28 46
44
37
27
35
16
35
78
58
78
1 120205
KNOB,GLUED,CAM,STYLE 2,2171B
77
4 910827
NUT,1/2-13,HEX,FG,BROWN
76
40 910826
NUT,3/8-16,HEX,FG,BROWN
75
1 891539
HOSE,1-1/4" VACUUM
74
1 891538
BARB,HOSE,1-1/4" NPT MALE
73
1 891537
ADAPTER,1-1/4" NPT FEMALE
72
1 891536
ELBOW,GRAY,1-1/4" PVC
71
1 891535
COUPLING,GRAY,1-1/4" PVC
70
2 891533
SNAP RING,30MM SHAFT
69
1 891531
STUD,1"-8 X 12,NYLATRON GS
68
6 880459
BEARING,3/8 ID X 7/8 OD
67
4 880458
BEARING,30MM ID X 37MM OD
66
1 119962
STUD,1/2-13 X 4.50,FG
65
1 119961
STUD,1/2-13 X 8.13,FG
64
2 119960
STUD,3/8-16 X 2.13,FG
63
4 119959
STUD,3/8-16 X 8.38,FG
62
4 119957
STUD,3/8-16 X 6.50,FG
61
2 119956
STUD,3/8-16 X 7.25,FG
60
1 119937
KNOB,GLUED,CAM,2171B
59
2 119934
BUSHING,SLIDER,ACTUATOR
58
1 119933
ECCENTRIC,CAM,STYLE 3,2171B
57
2 119614
LINK,10M,2171B
56
2 119613
LINK,5M,2171B
55
2 119612
LINK,CAM 3M,STYLE 3,2171B
54
1 119558
DOWEL,3/8 X 1.90,G10
53
2 118632
STUD,3/8-16 X 10.25,FG
52
8 118519
ROLLER,MAST,2171B
51
1 118518
CLAMP,BELT,2171B
50
2 118494
DOWEL,3/8 X 3.45,G10
49
4 118493
STANDOFF,3/8 X 2-1/2,G10
48
4 118492
BRKT.,ROLLER,2171B
47
2 118491
ROLLER,CARRIER,2171B
46
1 118147
STUD,1/2-13 X 9.5,FG
45
4 118144
STUD,3/8-16 X 4.50,FG
44
1 118142
STUD,3/8-16 X 13.87,FG
43
1 118092
SPROCKET ASSY.,B/S
42
2 118091
SPACER,THRUST,B/S
41
1 118085
PLATE,BODY,CLAMP
40
1 118084
BODY,CLAMP,BELT
39
1 118083
NUT,TENSION,BELT
38
1 118082
PLATE,BELT CLAMP
37
1 118081
BLOCK,BELT CLAMP
36
2 118078
PIPE,CUT,1.25 X 6.87,GRAY PVC
35
1 118076
ACTUATOR,118076
34
1 118073
BLOCK,COAX SUPPORT
33
2 118071
PILLOW BLOCK,LONG,B/S
32
3 118070
DOWEL, 1/8 X .95 G10
31
2 118069
IDLER,B/S
30
2 118068
DOWEL,3/8 X 2.50,G10
29
2 118066
BRACKET,IDLER,B/S
28
1 118065
NUT,RACK,POLAR
27
1 118064
GEAR,POLAR,2171B
26
1 118063
CYLINDER,POLAR,2171B
25
1 118062
PLATE,MAST,OUTER
24
1 118061
PLATE,MAST,INNER
23
1 118060
BLOCK,SUPPORT,MAST PLATES
22
1 118059
KNOB,GLUED,CAM LOCK
21
8 118058
DOWEL, 3/16 X 1.45 G10
20
2 118057
KNOB,GLUED,1/2" LINK
19
1 118052
CAM KNOB,NB
18
1 118051
LINK,NB,1"
17
1 118050
LINK,NB,1-1/2"
16
4 118049
DOWEL,3/8 X .63,G10
15
2 118048
ANCHOR,POLAR
14
1 118047
RACK,MACHINED,POLAR
13
1 118046
BOOM,POLAR,2171B
12
1 118045
CAM,CYLINDER,2171B
11
1 118044
CAM,BORESITE,2171B
10
2 118020
BLOCK, MAIN BEARING
9
3 118018
BEARING, POLAR BOOM
8
3 118017
BLOCK,BEARING,2171B POLAR
7
1 118016
BUSHING, PIVOT
6
2 118015
BUSHING #2, PIVOT
5
1 113493
ASSY,BUSHING,6.0" STINGER
4
2 109572
STUD,3/8-16 X 7.50,FG
3
2 109386
STUD,3/8-16 X 2.75,FG
2
2 109034
KNOB,1/2-13 X 1.1,GLUED
1
2 108990
CLAMP,STINGER
ITEM# 11810
0/QTY.
PART NUMBER
DESCRIPTION
CARRIER,B/S,2171B
1:4
118100
C
1
2
04/2012
X.XX
X.XXX
.005
.015
.5
NONE
REF DRAWING
ECN
REV
APPROVED
REVISIONS
DESCRIPTION
DATE
DO NOT SCALE DRAWING
ETS LINDGREN
SIZE
THIRD ANGLE PROJECTION
ENGINEERING
INITIAL
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
REMOVE ALL BURRS AND SHARP EDGES
SURFACE FINISH 63 RMS OR BETTER
FINISH
TOLERANCES ARE:
DECIMALS
±
±
±
ANGLES
DRAFTING
PERMISSION OF ETS LINDGREN
IS PROHIBITED.
ANY DUPLICATION OF THIS
PROPRIETARY INFORMATION
WITHOUT EXPRESS WRITTEN
DOCUMENT, WHOLE OR IN PART,
DATE
TITLE
OF
SHEET
DWG. NO.
An ESCO Technologies Company
SCALE
D
TM
REV.
04-19-12
SRK
JAD
JRC
ADDED 120205 TO BOM
11/21/13
C
