4.0 Mounting Instructions
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
The Model 3161 Series antennas are precision
measurement devices. Handle your antenna
with care.
Horizontal and vertical polarizations can be achieved by rotating the
antenna from one mount to the other.
The Model 3161 Series Octave Bandwidth Pyramidal Horn Antenna is equipped
with a standard 1/4–20 mount. The mount is placed so as not to interfere with
incoming electromagnetic energy.
Once mounted, remove the red cover from the Type N connector and attach a
cable between the antenna and a transmitting/receiving RF device.
Mount to 4-TR
Model 3161 Series antennas mount directly to an ETS-Lindgren 4-TR Tripod; no
additional hardware is required. Secure the mount onto the 4-TR by tightening
the1/4–20 UNC mount knob.
