3.0 Specifications
Electrical Specifications
• The VSWR indicated in the following table is that of the pyramidal horn
antenna and coax-to-waveguide adapter. The VSWR of the antenna by
itself is of the order of 1.1:1.
• The maximum continuous power indicated in the following table is
mainly limited by the coax-to-waveguide adapter. The antenna itself is
capable of handling continuous power on the order of 10
4
Watts to
10
7
Watts.
3161-01 3161-02 3161-03
Frequency
Range:
1.0 GHz
to
2.0 GHz
2.0 GHz
to
4.0 GHz
4.0 GHz
to
8.0 GHz
Antenna
Factor:
15.40 dB(1/m) 16.85 dB(1/m) 20.60 dB(1/m)
VSWR
With Feed:
1.6 1.5 1.3
Maximum
Continuous
Power:
550 W 500 W 250 W
Connector
Type:
Type N female Type N female Type N female
