T ABLE 3: M ODEL 3161-02 P OWER R EQUIREMENTS AT 1 M ETER
Freq
GHz
Gain
dB
Gain
Num.
AF
dB(1/m)
Field Strength
100 V/m 200 V/m 500 V/m
2.0 15.15 32.73 21.09 10.18 40.73 254.58
2.2 15.91 38.99 21.16 8.55 34.19 213.71
2.4 16.59 45.60 21.23 7.31 29.24 182.73
2.6 17.20 52.48 21.32 6.35 25.41 158.79
2.8 17.75 59.57 21.41 5.60 22.38 139.90
3.0 18.25 66.83 21.51 4.99 19.95 124.69
3.2 18.70 74.13 21.62 4.50 17.99 112.41
3.4 19.12 81.66 21.73 4.08 16.33 102.05
3.6 19.49 88.92 21.86 3.75 14.99 93.72
3.8 19.84 96.38 21.98 3.46 13.83 86.46
4.0 20.15 103.51 22.11 3.22 12.88 80.50
Specifications | 15
