T ABLE 1: M ODEL 3161-01 P OWER R EQUIREMENTS AT 1 M ETER
Freq
GHz
Gain
dB
Gain
Num.
AF
dB(1/m)
Field Strength
100 V/m 200 V/m 500 V/m
1.0 13.02 20.04 17.20 16.6 66.5 415.7
1.1 13.69 23.38 17.36 14.3 57.0 356.3
1.2 14.28 26.79 17.52 12.4 49.8 311.0
1.3 14.80 30.20 17.70 11.0 44.2 275.9
1.4 15.25 33.50 17.89 10.0 39.8 248.8
1.5 15.64 36.64 18.10 9.1 36.4 227.4
1.6 15.98 39.62 18.32 8.4 33.6 210.3
1.7 16.27 42.36 18.55 7.9 31.5 196.7
1.8 16.52 44.87 18.80 7.4 29.7 185.7
1.9 16.73 47.10 19.06 7.0 28.3 176.9
2.0 16.90 48.98 19.34 6.8 27.2 170.1
Specifications | 13
