Physical Specifications
3161-01 3161-02 3161-03
Height:
39.8 cm
15.6 in
23.1 cm
9.1 in
11.7 cm
4.6 in
Width:
53.1 cm
20.9 in
34.6 cm
13.6 in
17.4 cm
6.8 in
Depth:
88.0 cm
34.6 in
59.3 cm
23.3 in
31.8 cm
12.5 in
Weight:
8.0 kg
17.6 lb
5.0 kg
11.0 lb
2.0 kg
4.4 lb
Waveguide
Number:
WR-650 WR-320 WR-159
Power Requirements
The Model 3161 Series Octave Bandwidth Pyramidal Horn Antenna is an
efficient transmitting antenna, capable of generating high electric field strengths
using little power. For a given electric field strength, the required power can be
computed using the transmission equation:
Power Transmitted=
(Field Strength) Distance in meters)
(30 Numeric Gain)
P
E R
g
2 2
t
2
(
×
=
2
30
The typical power requirements in Watts for a given field strength computed from
the transmission equation for the Model 3161 Series are shown in Table 1
through Table 6. Distance is measured from the aperture of the antenna.
