EFCO S5500 Inside Glazed User Manual

Page 35

EFCO CORPORATION 6/2012

PART NO. Y552

Series 5500 Inside Glazed Installation Instructions

Section VI: Interior Drive-In Gasket & Glazing Bead

Installation

STEP #4 APPLY INTERIOR GLAZING BEAD COVER

Snap the interior glazing bead covers onto the inside glazed horizontals.

Remove any excess sealant that remains.

Note: The interior bead cover should be applied be-

fore the sealant at the ends of the glazing bead be-

gins to harden. If not, the sealant may need to be re-
moved where the cover slips onto the glazing bead.

INTERMEDIATE SHOWN, HEAD SIMILAR
