EFCO S5500 Inside Glazed User Manual
Page 22
EFCO CORPORATION 6/2012
PART NO. Y552
Series 5500 Inside Glazed Installation Instructions
Section III: Typical Anchorage Methods
NOTE: When welding, protect installed
metal and glass from weld splatter.
NOTE: The elevation of the structure must be within
the adjustment limits of the anchoring system. See
approved shop drawings for limitations.
WELDED DEAD LOAD ANCHORS
STEEL ANCHOR PER
SHOP DRAWINGS
Weld to building structure per
approved shop drawings.
BUILDING
STRUCTURE
