Standard head anchorage standard sill anchorage – EFCO S5500 Inside Glazed User Manual
Page 17
EFCO CORPORATION 6/2012
PART NO. Y552
Series 5500 Inside Glazed Installation Instructions
Section III: Typical Anchorage Methods
STANDARD HEAD ANCHORAGE
STANDARD SILL ANCHORAGE
ANCHOR BOLTS
WITH SLEEVES AS
REQ’D.
INTERIOR VIEW
Apply dead load
shims at anchors
and below verticals.
INTERIOR VIEW
ANCHOR BOLTS
AS REQ’D.
