4
Control Panel
Controls Description
1. Front right rapid burner control knob (3)
2. Rear right semi-rapid burner control knob (2)
3. Central triple-ring burner control knob (4)
4. Rear left semi-rapid burner control knob (2)
5. Front left auxiliary burner control knob (1)
6. Conventional oven thermostat knob (top oven)
7. Conventional oven switch knob (top oven)
8. Fan oven switch/thermostat knob (bottom main oven)
9. Electronic programmer (bottom main oven only)
Pilot lamps:
10. Bottom main oven temperature indicator light
11. Top oven temperature indicator light
Please note: This appliance incorporates a safety cooling fan which you will hear operating whenever
the oven or grill are in use. The cooling fan may also operate when the oven is switched off. This fan is to
reduce the external temperature of the appliance and cool the internal components.
9 8 7 6 5 4 3 1 2
11 10
Fig. 2
