CDA GB RV 701 SS - Manual (Page 26)

26
Replacing the Inner Pane of Glass
1. Make sure the door is locked open (see figs. 21, 22, 23).
2. Replace the inner pane:
– Check that the four rubber pads are in place (D in Fig. 25).
– Check that you are holding the pane the correct way. You
should be able to read the wording on it as it faces you.
– Insert the pane in the left E and right F slide guides (fig. 26),
and gently slide it to the retainers H (fig. 27).
– Unlock the oven door by opening it completely and closing
the lever A on the left and right hinges (Fig. 28).
A
Fig. 28
A
Fig. 26
Fig. 25
E
F
H
Fig. 27
H
D
E
F
