Installation Instructions
Vault w/ visor C-Scroll w/ visor Roundel w/ visor
These installation instructions are valid with the above Ametrix styles
Mounting Plate Dimensions In[mm]
Warning : Before starting any work ensure
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Large, OUTDOOR
P1R
(Pendant, 1-way, Remote ballast)
Visor and Non-Visor
Sheet 2 of 3
ADY071473 REV A(ECN070347)
