Parts list – Coral Industries Style Bypass (3/16 Frameless) - 20R1-P (If Purchased from a Plumbing Wholesaler) User Manual
Page 2
20R1-P 7/05
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting of this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes
in the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors
into the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C
leaning and care of your enclosure is important to its lasting beauty. We suggest using a nonabrasive liquid cleaner.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
A
SILL
A925
1
B
JAMB
A901
2
C
HEADER
A902
1
D
TOWEL BAR
A721
2
V
VINYL TRACK GUIDE
V499
1
E
TOWEL BAR BRACKET KIT
HFBB
1
8A X 1 FLAT HEAD SCREW
HA44
4
TOWEL BAR BRACKET
HBCL
4
TOWEL BAR BRACKET SLEEVE
HASL
4
BRACKET VINYL
V428/V208
4
TOWEL BAR DOOR BRACKET
HTBB
4
F
ROLLER
H342
4
M
8-32 X 3/8 TRUSS HEAD SCREW
H430
4
G
ROLLER FIN (I)
CA02
4
H
GUIDE
HA20
1
I
BUMPER
HB01
4
J
8A X 1 1/4 PAN HEAD SCREW
H480
6
K
ANCHOR
H002
6
L
8A X 3/8 TRUSS HEAD SCREW
H470
2
N
8A X 3/8 PAN HEAD SCREW
H901
1
PARTS LIST
DESCRIPTION
KEY
PART
FRAME PACKAGE
HARDWARE BAG
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
Pencil
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
QTY
(3/16" Masonry Bit for
Ceramic Tile)
(I)
Pre-Installed
