Page 2

2FG1P 11/05
PARTS LIST
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting of this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes
in the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors
into the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C
leaning and care of your enclosure is important to its lasting beauty. We suggest using a nonabrasive liquid cleaner.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Pencil
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
A
SILL
A925
1
B
JAMB
A901
2
C
HEADER
A920
1
D
VINYL TRACK GUIDE
V499
1
E
TOWEL BAR KIT
HT18/20/24/30
1
TOWEL BAR
2
ROUND BUSHING
4
PLASTIC WASHER
8
HANDLE / END CAP
4
F
ROLLER
H342
4
G
8-32 X 3/8 TRUSS HEAD SCREW
H430
4
H
GUIDE
HA20
1
L
8A X 3/8 PAN HEAD SCREW
H901
1
I
BUMPER
HB01
4
J
8A X 1 1/4 PAN HEAD SCREW
H480
6
K
ANCHOR
H002
6
M**
TOP CHANNEL/ROLLER FIN
**
A802
2
N**
PLASTIC POST
**
H906
4
O**
10-32 X 3/8 PAN HEAD SCREW
**
H905
42
DESCRIPTION
KEY
FRAME PACKAGE
QTY
PART
HARDWARE BAG
**
May be Pre-Installed
