063-GP 11/06
PARTS LIST
TOOLS NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Caulking Compound
File
Drill
Level
Masking Tape
KEY DESCRIPTION PART QTY
A SILL A855 1
B JAMB A942 2
C HEADER A101 1
D DOUBLE CHANNEL A911 1
E DRIP RAIL A710 / V667 1
F MAGNETIC DOOR STOP A954 1
G DRIP RAIL VINYL VS91 1
H MAGNETIC STRIP H170 1
I * DRIP RAIL TAPE * HT52 1
P DRIP RAIL PLUG HA28 1
J 8A X 1 PAN HEAD SCREW H475 8
K 8A X 3/8 TRUSS HEAD SCREW H470 22
L ANCHORS H002 8
M + PULL HANDLE KIT + HSAD
6-32 X 1 1/4 PAN HEAD SCREW H485 2
EXTERIOR PULL HANDLE HA31 1
INTERIOR PULL HANDLE HA32 1
FRAME PACKAGE
* Pre-Installed + May be Pre-Installed
HARDWARE BAG
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surround with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes in
the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors into
the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C leaning and care of your enclosure is important to its lasting beauty. A nonabrasive liquid cleaner is recommended.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
