Copernicus RC107 - Manual (Page 5)

RC107 - Version D - 3 June 2014 - Copernicus Educational Products Inc.
3
You will need:
(Not to Scale)
4x
Actual Size:
Build Rear Frame
!
Note - install Rear Whiteboard Hook
before screwing stretcher into place
Ensure hook faces back of unit!
L
R
R
L
Stretcher
2x Rear Whiteboard
Hook
2x Upper Frame
1 Left, 1 Right
2x
1
2
RC107
Choose stretcher location based on which unit you
are building.
Tech Easel
(RC108, RC109, RC110)
M6x25mm M6x35mm
C
2x
D H
4-6x 2x
D
C
D
D
D
G
G
H
H
H
H
H
