Before beginning, you should have:
Additional tools required: Adjustable wrench
Base
2x
Regal Reading/Writing Center
™
- Parts
3” Caster
4x
Center Frame
1x
Lower Frame
1 Left, 1 Right
2x
Upper Frame
1 Left, 1 Right
2x
Stretcher
2x
Front Frame Support
1 Left, 1 Right
2x
Front Frame
1x
Tub Channel
4x
Chart Loop Hook
2x
Hardware
Actual Size
Contents - Box 1
In Box 1
In Box 1
Whiteboard Channel
1x
Contents - Box 2
Removable Rear Whiteboard
1x
Rear Whiteboard Hook
2x
Spacer
No Thru Holes
2x
Safety Cap Premium
Bookledge
1x
Open Tub
4x
(Not to scale)
x2
x1
A
M5 x 35mm
2x
B
M6 x 20mm
2x
C
M6 Lock Washer
20x
D
M8 Lock Washer
12x
E
M6 Barrel Nut
12x
F
M6 x 25mm
2x
M6 Acorn Nut
2x
M6 x 35mm
16x
M6 x 15mm
10x
G
H
i
i
