Assemble the Top Arm & Headphone Holder
You will need:
(Not to Scale)
Actual Size:
To easily assemble the Top
Arm, adjust the height to the
lowest position then assemble
the pieces together.
Top Arm
1x
M6 x 45mm
1x
B
M6 Lock Washer
1x
C
Headphone Holder
1x
The headphone holder holds
up to two headphones.
