Control Input Function Definitions (Note: All control inputs are +power enabled

wire Color

Function

Description

GRN/BLK

Level 1

Level 1 Emergency Mode

WHT/BLK

Level 2

Level 2 Emergency Mode

RED/BLK

Level 3

Level 3 Emergency Mode

ORG/BLK

Take Down lights

Take Down Lights Steady Burn (overrides Take Down Flash)

BLU/BLK

Rear Cut-Off

Blacks-Out Rear Facing LEDs

GRN/WHT

Front Cut-Off

Blacks-Out Front Facing LEDs

RED/WHT

Right Alley Light

Right Alley Steady Burn (overrides Alley Light Flash)

BLK/WHT

Left Alley Light

Left Alley Steady Burn (overrides Alley Light Flash)

WHT

ArrowStik® Flash

ArrowStik Flash (overrides L1, L2 & L3 for rear of light bar)

BLK/RED**

Pattern Select

Pattern Select for ArrowStik, L1, L2 & L3, enables test mode)

BLK

Take Down Flash

Enables Take Down Lights Wig/Wag Flash

RED*

ArrowStik Left

Left ArrowStik (overrides L1, L2 & L3 for rear of light bar)

GRN

Cruise Lights

End LEDs only (overridden by all other functions except for Dim)

ORG*

ArrowStik Right

Right ArrowStik (overrides L1, L2 & L3 for rear of light bar)

BLU

Light bar DIM

Sets LED to Dim mode

BLU/WHT

Alley Light Flash

Enables Alley Light Wig/Wag Flash

Table 1b

The Pattern Select wire is the BLK/RED wire as noted above in the sixteen conductor light bar control cable and is activated by

momentarily touching the wire to +power.

Factory Default

Lighting

Level

Flash Pattern Description

L1 L2 L3

Factory Default

Level 2

15

1

5

Fast Alternating Quad Flash

16

2

6

Alternating Two Flash

17

3

7

Alternating Single Flash

18

4

8

Fast Picket Fence Quad Flash

19

5

9

Slow Picket Fence Quad Flash

20

6

10 Alternating Quad Flash

21

7

11 Slow Alternating Six Flash

22

8

12 Alternating Six Flash

23

9

13 Variable Rate Even/Odd Flash

24

10

14 Alternating Quad Flash 75 FPM (NFPA)

Factory Default

Level 1

1

11

15 Fast Alternating Quad Flash (Rear Only)

2

12

16 Fast Even/Odd Quad Flash (Rear Only)

3

13

17 Alternating Quad Flash (Rear Only)

4

14

18 Alternating Six Flash (Rear Only)

5

15

19 Variable Rate Even/Odd Head Flash (Rear Only)

6

16

20 Fast Alternating Quad Flash (Front Only)

7

17

21 Fast Even/Odd Quad Flash (Front Only)

8

18

22 Alternating Quad Flash (Front Only)

9

19

23 Alternating Six Flash (Front Only)

10

20

24 Variable Rate Even/Odd Head Flash (Front Only)

Factory Default

Level 3

11

21

1 Cycle Flash (cycles through multiple flash patterns)

12

22

2

Simultaneous Quad Flash (all LEDs) 75 FPM (NFPA)

13

23

3

Null Flash (no flashing LEDs - only Steady Burns if equipped

14

24

4

Rapid Quad Flash Picket Fence

Table 1A
