Notes: *When the Pattern Select wire is connected to +power when all other inputs are off, test mode is enabled to exercise all outputs
in sequence until +power is removed from the wire.
**When the ArrowStik Left and ArrowStik Right wires are both connected to +power, the Center-Out ArrowStik function is activated.
The priority for the 3-Level inputs is L3, L2 then L1 in that order. In other words, if power is applied to both the L1 and L2 inputs, the L2
function will be enabled.
If the lightbar is equipped with Steady Burning LED light heads, these heads are enabled with the 3-Level input wires. The jumper plug must
be moved to JP1, JP2 or JP3 to select the 3-Level input which will enable the Steady Burning LED heads, (see Figure 1).
The Steady Burn function for both the Takedown and Alley lights will always override the Wig/Wag Flash function.
The Cruise Light function is mutually exclusive with all other functions. If any other input has +power applied, the Cruise Lights will be turned
off.
The Dim function sets the brightness of the LEDs in both the ArrowStik mode and Emergency Warning Flash mode.
The Front Cut and Rear Cut functions must be used with the greatest care to ensure that the use of these functions does not diminish the
effectiveness of the Emergency Warning signal.
6
Factory Default
Lighting Level
Flash Pattern Description
L1 L2 L3
Factory Default Level 2 14 1 4 Fast Alternating Quad Flash
15 2 5 Alternating Two Flash
16 3 6 Alternating Single Flash
17 4 7 Fast Picket Fense Quad Flash
18 5 8 Slow Picket Fense Quad Flash
19 6 9 Alternating Quad Flash
20 7 10 Slow Alternating Six Flash
21 8 11 Alternating Six Flash
22 9 12 Variable Rate Even/Odd Flash
23 10 13 Alternating Quad Flash 75 FPM (NFPA)
Factory Default Level 1 1 11 14 Fast Alternating Quad Flash (Rear Only)
2 12 15 Fast Even/Odd Quad Flash (Rear Only)
3 13 16 Alternating Quad Flash (Rear Only)
4 14 17 Slow Alternating Six Flash (Rear Only)
5 15 18 Variable Rate Even/Odd Head Flash (Rear Only)
6 16 19 Fast Alternating Quad Flash (Front Only)
7 17 20 Fast Even/Odd Quad Flash (Front Only)
8 18 21 Alternating Quad Flash (Front Only)
9 19 22 Fast Alternating Six Flash (Front Only)
10 20 23 Variable Rate Even/Odd Head Flash (Front Only)
Factory Default Level 3 11 21 1
Cycle Flash (cycles through multiple flash patterns)
12 22 2 Simultaneous Quad Flash (all LEDs) 75 FPM (NFPA)
13 23 3 Null Flash (no flashing LEDs - only Steady Burns if equipped
Table 1A
