Code 3 LED X Side-By-Side User Manual

Page 5

background image

5

Figure 2

DUAL LED GASKET

DUAL LED HOUSING

#8 SMS 1" LONG

PART DESCRIPTION

1

1

2

QUA.

ITEM NO.

P/N

1

2

3

T09477

T09338

HORIZONTAL

VERTICAL

SPREADING

LXTABF

LXTABFV

LXTABFW

LXTAF

LXTAFV

LXTAFW

Optic Variations

Black Finish

Bright Finish
