8
Parts & Exploded
Views
Note: All of the components illustrated are for the 45 series. They are shown for reference only. The
procedures outlined within are generic procedures and are for use in the 65 & 85 series as well.
* Gasket, item 4, only used for Standard Units.
Bezel, item 5, and Bezel Gasket, item 6, only used for Bezeled Units.
Turn Arrow Insert T04580 only used with 65STA.
Standard Unit, Figure 4 Bezeled Unit, Figure 5 1 2 3 4 * 5 * 6 * 7
Code 3 Model Number - Description Code 3 Model Number - Description
Base Lens Lens O-
Ring
Gasket Bezel Bezel
Gasket
Bag of
Screws
45R - LED Perim, 7x3, Red 45BZR - LED Perim, 7x3, Red, Bezel -- T07891
45A - LED Perim, 7x3, Amber 45BZA - LED Perim, 7x3, Amber, Bezel -- T07892
45B - LED Perim, 7x3, Blue 45BZB - LED Perim, 7x3, Blue, Bezel -- T07893
45W - LED Perim, 7x3, White 45BZW - LED Perim, 7x3, White, Bezel -- T07894
45RB - LED Perim, 7x3, Red-Blue 45BZRB - LED Perim, 7x3, Red-Blue -- T07894
45RA - LED Perim, 7x3, Red-Amber 45BZRAW - LED Perim, 7x3, Red-Amber -- T07894
45RW - LED Perim, 7x3, Red-White 45BZRW - LED Perim, 7x3, Red-White -- T07894
45AW - LED Perim, 7x3, White-Amber 45BZAW - LED Perim, 7x3, White-Amber -- T07894
45STR - LED STT, 7x3, Red 45STBZR - LED STT, 7x3, Red -- T07895
45STA - LED Turn, 7x3, Amber 45STBZA - LED Turn, 7x3, Amber -- T07896
65R - LED Perim, 6x4, Red 65BZR - LED Perim, 6x4, Red, Bezel -- T07901
65A - LED Perim, 6x4, Amber 65BZA - LED Perim, 6x4, Amber, Bezel -- T07902
65B - LED Perim, 6x4, Blue 65BZB - LED Perim, 6x4, Blue, Bezel -- T07903
65W - LED Perim, 6x4, White 65BZW - LED Perim, 6x4, White, Bezel -- T07904
65RB - LED Perim, 6x4, Red-Blue 65BZRB - LED Perim, 6x4, Red-Blue -- T07904
65RA - LED Perim, 6x4, Red-Amber 65BZRAW - LED Perim, 6x4, Red-Amber -- T07904
65RW - LED Perim, 6x4, Red-White 65BZRW - LED Perim, 6x4, Red-White -- T07904
65AW - LED Perim, 6x4, Amber-White 65BZAW - LED Perim, 6x4, Amber-White -- T07904
65STR - LED STT, 6x4, Red 65STBZR - LED STT, 6x4, Red, Bezel -- T07905
65STA - LED Turn, 6x4, Amber 65STBZA - LED Turn, 6x4, Amber, Bezel -- T07906
85R - LED Perim, 9x7, Red 85BZR - LED Perim, 9x7, Red, Bezel -- T07911
85A - LED Perim, 9x7, Amber 85BZA - LED Perim, 9x7, Amber, Bezel -- T07912
85B - LED Perim, 9x7, Blue 85BZB - LED Perim, 9x7, Blue, Bezel -- T07913
85W - LED Perim, 9x7, White 85BZW - LED Perim, 9x7, White, Bezel -- T07914
T07928
T07926 T07920 T07917 T07923
T07927 T07921 T07918 T07924
T07925 T07919 T07916 T07922
Model 45,45STA&45STR 7x3 Perimeter 62 1.0 0.5 0.5 0.3
Model 65, 6x4 Perimeter 76 1.0 0.5 0.5 0.3
Model 85, 9x7 Perimeter 124 1.5 0.8 0.8 0.4
65STR - 6x4, Red (Stop or Turn Config.) 54 0.7 0.4 0.4 0.2
65STR - 6x4, Red (Tail Configuration) 0.05 n/a 0.04 n/a
65STA - 6x4, Amber Turn 54 0.7 0.4 0.4 0.2
Code 3 LED Perimeter Light Models
Average Current Draw, Amps
Number
of LED's
Steady
Burn
13.8VDC
Flashing
13.8VDC
Steady
Burn
24.0VDC
Flashing
24VDC
