8

FOR NFPA COMPLIANT INSTALLATION, SELECT QUAD

OR FIVE FLASH MODES

WARNING: To achieve the maximum performance from your strobe tubes, do not mix Helix tubes and

Linear Tubes. Run all Helix or all Linear strobe tubes on the odd numbered outputs of the power

supply (1,3,5), and run all of the alternate style tubes on the even numbered outputs. (2,4,6). Mixing

strobe tubes on the even or odd numbered outputs will cause one type to flash brighter than the other

type and will reduce the life expectancy of the brighter flashing tube.

MAINTENANCE

The CPS690 Remote Strobe Power Supply has been designed to provide trouble free service. In case of

difficulty, refer to the Troubleshooting section. Periodic inspection of power supply wiring, and strobe light head

connections for shorted or open wires will assure trouble free operation. The primary cause of short circuits

has been found to be wires passing through firewalls, roofs, etc.

FIGURE F

FLASH PATTERN SELECTION

L1

L2

L3

L4

L5

FLASH MODE

*

-

-

-

-

Quad Flash

-

*

-

-

-

Double Flash

-

-

*

-

-

Cycle Flash 1

-

-

-

*

-

Quad Flash Slow/Fast

-

-

-

-

*

Five Flash All Heads

*

*

-

-

-

Quad Flash Slow

*

-

*

-

-

Double-Triple Flash

*

-

-

*

-

Double-Double Flash

*

-

-

-

*

Fast Single Flash

-

*

*

-

-

Triple Flash

-

*

-

*

-

Variable flash

-

*

-

-

*

Cycle Flash 2

* Indicated LED is lighted
