Model 7620U Bench Scale User’s Manual 7
Initial Setup
Unpacking the Scale
Installing the Scale
1. Check container for any obvious evidence of
damage.
2. Remove contents of the shipping container.
3. Inspect the scale for shipping damage.
Immediately report any damage to the
shipper.
1. Mount the scale on a stable, level surface
free from air currents and vibration. Be sure
the scale platter does not touch any adjacent
surfaces.
2. If you want to install the scale surface flush
with a countertop, use these dimensions to
guide construction:
7620U Platform Minimum Cutout
Dimensions Dimensions
356 mm Wide 375 mm Wide
318 mm Deep 337 mm Deep
104 mm Minimum Height
3. Loosen the plastic collars on the leveling
feet. Level the scale by using the level bubble
under the scale platter as a guide. Be sure all
four feet are in firm contact with the counter,
then tighten all collars.
4. Make sure all power cords, remote display
cables, etc. are not touching the live weighing
surface.
5. Plug the unit into an appropriate voltage
outlet, properly grounded.
