Ⅹ.Key Definition summary:
KEY MODE DEFINITION
Normal weighing mode
Enter or exit HOLD mode; output the
data as per P4,P5,P6 setting
Setup mode/Calibration
mode
Shift the flashed position from right to
left HOLD
/PRINT
Displaying A/D code or
input voltage mode
No Function
Normal weighing mode
Choose weight units, refer P8, P9,
P10, P11 setting and Table3,Table4.
Setup mode/Calibration
mode
Change the digit on flashed position
and click this button to add 1.
UNIT
Displaying A/D code or
input voltage mode
Choose the weight inner code or input
working voltage to be displayed.
Normal weighing mode Tare the weight
Setup mode/Calibration
mode
Confirm the displayed parameters or
input data, and go to next step
TARE
Displaying A/D code or
input voltage mode
Choose filtered or un-filtered weight
A/D data
Normal weighing mode Zero function or Power off the scale.
ON/OFF/
ZERO Setup mode/Calibration
mode/Displaying A/D code
or input voltage mode
Exit and back to normal work mode
ON/OFF/
ZERO
+
HOLD
/PRINT
Normal weighing mode
(more than 3s)
Go to Show A/D code or input
working voltage of indicator mode
26
ON/OFF/
ZERO
+
UNIT
Normal weighing mode
(more than 3s)
Enter setup mode
ON/OFF/
ZERO
+
TARE
Normal weighing mode
(more than 3s)
Enter calibration mode when
Ⅺ.Parameters setting summary: SEE SPECS
Para-
meter
x/xy
Factory
Set
Setting
P1.xy 00-15 05
Auto-off time: no auto-off;
01-15 minutes auto-off time
P2.x 0, 1, 2 2
0=only Hold function; 1=only Print function;
2=Print and Hold function,
P3.xy
0,1,2,
3-50
2
0=no hold function; 1=hold lager weight
reading; 2=auto release hold function when
weight is below 10d and auto-hold new stable
weight (more than 10d); 3-50=unchangeable
reading when the variety is within +3~50d
P4.x
0,1,2,3,4,
5,6,7
2
0=no RS232 function; 1=output display data
when PRINT pressed; 2=output gross, tare and
net weight when PRINT pressed;
3=continuously output display data; 4=
continuously output gross, tare and net weight;
5=output display data one time when scale is
stable; 6=output gross, tare and net weight one
time when scale become stable; 7=Bio-RS232
compatible to NCI-SP1
P5.x
0, 1, 2, 3,
4
3
Baud rate for RS232: 0=1200bps, 1=2400bps,
2=4800bps, 3=9600bps, 4=19200bps
P6.x 0, 1, 2 0 RS232 format: 0=8N0, 1=7O1, 2=7E1
