④
w1w2w3w4w5w6w7u1u2H1H2H3
---Scale is stable, and the current weight unit is kg or lb. With or without decimal
point and the position is as per the P9 setting and current unit.
⑤
w1w2w3w4w5lbw6w7H1H2H3
Or
w1w2w3w4lb w5w6w7ozH1H2H3
----The current unit is lb: oz.
(2) Command: S (53h 0dh)
Response: H1H2H3
(3) Command: Z (5ah 0dh)
Response: Zero function is activated and it returns to current scale status. just
like pressing ZERO/ON/OFF button:
H1H2H3
If ZERO function cannot be activated, it will return to current scale status.
(4) Command:
T (54h 0dh)
Response: TARE function is activated, and then returns scale status. just like
pressing TARE button:
H1H2H3
If TARE function cannot be activated, it will return to current scale status.
(5) Command:
U (55h 0dh)
Response: Changes units of measure and return scale status with new units,
just like pressing UNIT button. The new measure unit should be allowed to
use as per P11 setting.
u1u2 H1H2H3
If the weight unit is lb:oz, U1U2= lb oz
(6) Command: L (4ch 0dh)
Response: If Hold function can be activated, it will enable/disable hold (lock)
function, like the HOLD key is pressed, and returns scale status.
H1H2H3
(7) Command: X (58h 0dh)
Response: power off the scale, just like press down the ON/OFF key to turn
off the scale.
20
(8) Command: all others
Response: Unrecognized command
?
2.5) Output status bit meaning:
Table5: The status bits definition:
Bit Byte 1 (H 1 ) Byte 2 (H 2 ) Byte 3 (H 3 )
0=stable 0= not under capacity
0
1= not stable 1= under capacity
0= not at zero point 0= not over capacity
1
1= at zero point 1= over capacity
01=normal work mode
10= hold work mode
00=not define
11= not define
0= gross weight
2 always 0 always 0
1= net weight
0= eeprom OK
3
1= eeprom error
always 0 always 0
4 always 1 always 1 always 1
5 always 1 always 1 always 1
6 always 0 always 1 always 0
7 parity Parity parity
Ⅶ.
Relationship of capacity and the setting of P7, P8 and P9:
Table6: (Capacity unit is kg or lb)
Division set by P8 and P9（P8=0） Resoluti
on set by
P7
0.0001 0.001 0.01 0.1 1 10
500 0.0500 0.500 5.00 50.0 500 5000
600 0.0600 0.600 6.00 60.0 600 6000
750 0.0750 0.750 7.50 75.0 750 7500
800 0.0800 0.800 8.00 80.0 800 8000
1000 0.1000 1.000 10.00 100.0 1000 10000
21
