AVer FD2000 - Manual (Page 6)

2
Specifications
Hardware
RAM 256MB
Flash 256MB
Image Sensor 1/3” CMOS (2 megapixels)
Lens Type Fixed lens, f=3.4mm
Electric Shutter 1/25~ 1/8192 sec (PAL); 1/30~ 1/8192 sec (NTSC)
I/O N/A
Video Out N/A
Audio In 1 (built-in microphone, mono type)
G.711 (64K)
Audio Out N/A
Power over Ethernet Yes
Power Consumption PoE Class 0 (IEEE802.3af): 5.5W
This unit operates with PoE as power supply only.
Dimensions Ø : 97 x 104.5 H (mm)
Weight 380g
Network
Ethernet Ethernet (10/100 Base-T), RJ45 connector
Network Protocol IPv4, HTTP, TCP, RTSP/RTCP/RTP, ICMP, UDP, IGMP,
DNS, DHCP, ARP, NTP
System
Video Resolution
1080p(1920x1080), 720p(1280x720), VGA(640x480),
CIF(352x240), QVGA(320x240)
Video Adjust Brightness, Contrast, Saturation, Sharpness, Shutter
Speed, Day-Night Mode, WDR, Backlight Compensation.
Triple Streaming Yes
Image Snapshot Yes
Full Screen Monitoring Yes
Privacy Mask Yes,4 different areas
Compression Format H.264/ MJPEG
Video Bitrates Adjust Yes (CBR/VBR)
