Alumax K-KC4Z User Manual
Page 7
7
2
MOUNT THE WALL JAMBS.
2A. Reposition one of the wall jambs (#1) on the shower
threshold.
.
B
2 Mark drilling location.
2C. With a 1/4” drill bit, drill 4 holes.
2D.
Insert 4 wall plugs (#13) and put in each a drop of
silicone.
2E.
Secure the wall jamb (#1) using the 1 3/8” screws
(#16).
2F. Repeat the same step for the other wall jamb.
2A
2B
2C
1
1
2D
2E
