DOOR INSTALLATION
INTERIOR
SHOWER SIDE
Shims
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
7a.
7b.
Install the rollers on the door panel so
that the rollers point towards the outside
of the shower. The hole of the handle
must always be on the opening side of
the door.
Install the bottom sliders on the door
panel while placing the hooks towards
the outside of the shower. Place the
bottom slider shims on the hooks.
7A
7B
