4
4 5 8 10
12 13 14
PROVIDED HARDWARE
17 15 16
11a 11b
11
18
19a 19b
ITEM HARDWARE QTY
4 SET OF HANDLES 2
5 SIDE GASKET 4
8 SIDE GASKET WALL JAMB SIDE 4
10 MAGNETIC DOOR GASKET 1
11 GLASS SUPPORT 8
12 BOTTOM SLIDER SHIM 4
13 WALL PLUG 8
14 SCREW (M4 x 8) 8
15 SCREW CAP 8
16 SCREW (M4 x 35) 12
17 SCREW (M4 x 8) 8
18 EXPANDER CAP 2
19 CONNECTOR 2
20
WALL JAMB CAP
19 20
