Parts listing – Alumax K-KC4Z User Manual
Page 3
3
1
2
NOTE
XX REFERS TO THE MATERIAL FINISH
11- Bright Chrome
12- Bright Brass
25- Brushed Nickel
29- Oil Rubbed Bronze
PARTS LISTING
4
3
5
6
ITEM
PARTS
QTY
1
WALL JAMB
2
2
EXPANDER
2
3
FIXED PANEL
2
4
SET OF HANDLES
2
5
DOOR SIDE GASKET
4
6
DOOR PANEL ASSEMBLY
2
7
BOTTOM TRACK
2
8
SIDE GASKET WALL JAMB SIDE
2
9
TOP TRACK
2
10
MAGNETIC DOOR GASKET
2
11
GLASS SUPPORT
8
7
11
9
10
