MODEL MIN (in / cm) MAX (in / cm)
32 31 1/4” (79cm) 32” (81cm)
36 34 1/4” (87cm) 35” (89cm)
42
40 3/8”
(102.5cm)
41 1/8” (104cm)
1
CENTER AND INSTALL THE WALLJAMB
1
1B.
Refer to the limits given (Min/Max),position and center
the wall jambs (#1) on the shower threshold.
1A.
Trace outer edge of wall jambs.
1A
1B
