TOOLS AND MATERIAL REQUIRED
PENCIL
DRILL
SILICONE
SCREWDRIVERS
CUTTING PLIER
LEVEL
TAPE MEASURE
1/4˝
& 1/8˝ DRILL BITS
MALLET
BLOCK
LONG NOSE LOCKING PLIER (X2)
INSTALLATION OF COMPONENTS
INSTALLATION MANUAL
PXL4836
*
To install the shower door on ceramic tiles, use a 1/4’’ drill bit for ceramic tiles
*
• Wall Jamb
see page 28
STEP 1
• Threshold
see page 29
STEP 2
• Fix & return panel
see page 30
STEP 3
• Door panel & hinges
see page 31
STEP 4
• Expander
see page 32
STEP 5
• Handle
see page 33
STEP 6
• Support bar
see page 34
STEP 7
• Sealing
see page 35
STEP 8
