813 sealing – Alumax M-PD93X User Manual
Page 13
8
13
SEALING
INSTALLATION MANUAL
8a.
8b.
8c.
8d.
Use a mallet to install the side gasket on the
side panels. Place the textured side towards
the outside of the shower.
Use a mallet to install the magnetic gasket
on the door and return panels. The magnetic
gasket must close in point on the side of the
handle hole.
Silicone the outside of the shower, between
the wall and the wall jamb, bellow of the
panel and the return panel.
Wait 24 hours before using the shower to dry
the silicon.
HOURS
8d
8c
INTERIOR
SHOWER SIDE
8a
8b
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
