Alumax P-DRA1Y User Manual
Page 15
15
STOPPERS ADJUSTMENT
11
WALL SIDE GASKET INSTALLATION
10
Adjust the position of the stoppers (3) so as to
ensure a maximum opening and closing range.
Ensure that the sliding door gasket (10) is forced
against the wall when the door is closed.
Thoroughly clean the edge of thesliding door,
closest to the side where the handle is
located. Apply the door gasket (other half of
gasket from Step 1) (10) to this edge
of the sliding door (6).
INTERIOR
SHOWER SIDE
6
10
3
10
