14
SILICONE 12
10
Adjust the position of the stoppers (3) so as to
ensure a maximum opening and closing range.
Ensure that the sliding door gasket (9) is forced
against the wall.
Ajuster le positionnement des butoirs (3)
afin d’obtenir une ouverture ainsi qu’une
fermeture optimale de la porte coulissante.
Assurer que le joint de rétention (9) de la
porte coulissante s’écrase contre le mur.
Apply silicone between the bottom of the fixed
panel and the threshold of the base. Silicone
application along the length of the threshold is
also suggested. In both cases, it is done from
the outside of the shower area.
HOURS
STOPPERS 11
3
DOOR OPEN
DOOR CLOSED
APPROX.
3” (76.2 mm)
7
6
9
3
