7a 7b, Wall brackets – Alumax P-DR1W-48-60 User Manual

Page 10

background image

10

1

2

Mark the screw locations on the walls on both

sides of shower. Remove the running rail (1)

s

ll

a

w

n

i

s

e

l

o

h

l

li

r

D

.

)

2

(

s

t

e

k

c

a

r

b

l

l

a

w

e

h

t

m

o

r

f

until wall stud is reached with a drill bit intended

for ceramic tiles.

Fasten the wall brackets (2) with #12-3 (18).

Insert fixed panel (7) back, ensuring that it’s

placed in the bottom glass clips (11) (13).

Slide expander (E) over wall bracket (2) and fas-

ten set screws

7

WALL BRACKETS

2

WALL STUD

2

7A

7B

18

7

2

E

11

13
