Ту^е of camera: 35mm single-lens reflex (SLR)

Picture format: 24mm x 36mm (35mm film format)

Lens mount: Nikon F mount (bayonet type)

Lenses available: Nikkor 50mm f/1.4, f/2 or 55mm

f/1.2 as standard; more than 50 Nikkor lenses in all

Shutter: Vertical-travel focal-plane shutter; speeds of

from 8 seconds to 1/1000 second and “B”; automatic

shutter speed selection available when set to "A” set
ting; shutter release via shutter button or self-timer

Flash synchronization: Automatic selection as shutter

speed is manually set; hot-shoe contact (ISO-type)
with built-in safety switch provided;one threaded PC

terminal provided for off-camera flash operation

Synchronization range: 1/1000 ~ 8 sec. and “B” for

flashbulbs; 1/125 ~ 8 sec. and “B” for electronic

flash

Accessory shoe: ISO-type built into finder housing; fit

ted with hot-shoe contact and electric safety switch
which turns on contact as flash unit is mounted

Viewfinder: Fixed eyelevel pentaprism type with built-

in through-the-lens (TTL) exposure meter; shutter
speed indicated to the left within the viewfield

Focusing screen: Matte Fresnel field with central split-

image rangefinder surrounded by microprism ring;

12mm diameter reference circle defines area of meter

center-weighting; similar to Nikon Type К screen

Reflex mirror: Instant-return type; lockup lever pro

vided

FEATURB/SPECIFICATIONS
